Light painting with a CNC router

Arduino TeamMarch 6th, 2019

Maker Jeremy S. Cook has experimented with both CNC machinery and light painting in the past, and decided to combine these two skills into a new artistic device.

– Werbung –
– Werbung –

His setup uses a web app found here to program a CNC router as a sort of dot matrix printer. But instead of a pen, pencil, brush or other marking utensil, it uses a button as an input to the onboard Arduino Nano when pressed to the router’s surface.

– Werbung –

From this input, the Arduino then commands a diffused RGB LED to “mark” the surface with light, painting an image on the camera’s exposed sensor.

– Werbung –

Code and print files are are available on GitHub if you’d like to try your own light art experiments!

[youtube https://www.youtube.com/watch?v=Y_4NdVgSwuA?feature=oembed&w=500&h=281]

– Werbung –

Website: LINK
